Overview
The Multi Media Port Replicator provides the following:
„ SelectBay, which accommodates
• CD-ROM
drive
• DVD-ROM drive
• SelectBay HDD Adaptor II (with 6, 12 or 18 GB secondary hard disk
drive)
„ Five ports
• Serial
• Parallel
• External
monitor
• USB
• PS/2™ mouse/keyboard port
„ Jacks
• Line-out
• LAN
• DC-IN (two types)
„ PC card slot that accommodates a 5 mm card (type II)
The USB and the PC card slot can be used in addition to those on the
computer.
You must connect an AC adaptor to use the Multi Media Port Replicator’s
USB port or PC card slot.
You can use the external monitor port on either the computer or on the
Multi Media Port Replicator, but not both at the same time.
