14 User’s Manual Multi Media Port Replicator
User's Manual – Port_Rep.doc – PART 01 -- ENGLISH – Printed on 13/03/00 as 01_PRep
GB
Computer connector The cable for computer connection is attached to
this connector.
Do not use the cable to connect two computers or two Multi Media Port
Replicators or other expansion devices.
DC IN 15V
DC IN There are two types of DC IN jacks: one for a
square connector and one for a round connector.
Left side
Refer to Figure above for the location of items on the Multi Media Port
Replicator’s left side.
Security lock slot This slot lets you secure a cable to the Multi
Media Port Replicator to deter theft. Attach the
other end of the cable to a desk or other large
object.
AC adaptor
The AC adaptor converts AC power to DC power and reduces the voltage
supplied to the Multi Media Port Replicator and computer. It can
automatically adjust to any voltage from 100 to 240 volts and to a
frequency of either 50 or 60 hertz, enabling you to use the computer in
almost any country. It supplies four amperes of current.
The AC adaptor
You can also use a Toshiba three-ampere AC adaptor. Refer to the
AC adaptor section in Chapter 2, Connections.
