The Advanced MCACC menu
10
96
En
Checking MCACC Data
At the procedure of Automatically conducting
optimum sound tuning (Auto MCACC) on
page 39, the procedure of Automatic MCACC
(Expert) on page 87 or after fine-adjusting at
Manual MCACC setup on page 90, you can
check your calibrated settings using the GUI
screen. The data can be transferred to a
computer using a USB device to check it on the
computer’s screen as well.
1
Press
, then press HOME
MENU.
A Graphical User Interface (GUI) screen appears
on your TV. Use
/// and ENTER to
navigate through the screens and select menu
items. Press
RETURN to confirm and exit the
current menu.
2
Select ‘MCACC Data Check’ from the
Home Menu.
3
Select the setting you want to check.
•
Speaker Setting – Used to check the
settings of the speaker systems. See
Speaker Setting below for more on this.
•
Channel Level – Used to check the output
level of the different speakers. See Channel
Level below for more on this.
•
Speaker Distance – Used to check the
distance to the different speakers. See
Speaker Distance below for more on this.
•
Standing Wave – Used to check the
standing wave control filter settings. See
Standing Wave on page 97 for more on this.
•
Acoustic Cal EQ – Used to check the
calibration values of the listening
environment’s frequency response. See
Acoustic Cal EQ on page 97 for more on
this.
•
Output MCACC data – See Output
MCACC data on page 97 for more on this.
4
Press RETURN to go back to the MCACC
Data Check menu, repeating steps 2 and 3 to
check other settings.
5
When you’re finished, press RETURN.
You will return to the
Home Menu.
Speaker Setting
Use this to display the speaker size and
number of speakers. See Speaker Setting on
page 102 for more on this.
1
Select ‘Speaker Setting’ from the MCACC
Data Check menu.
2
Select the channel you want to check.
Use
/ to select the channel. The
corresponding channel on the layout diagram
is highlighted.
Channel Level
Use this to display the level of the various
channels. See Channel Level on page 103 for
more on this.
1
Select ‘Channel Level’ from the MCACC
Data Check menu.
2
When ‘MCACC’ is highlighted, use
/
to select the MCACC preset you want to
check.
The level of the various channels set at the
selected MCACC preset is displayed. ‘
---’ is
displayed for channels that are not connected.
Speaker Distance
Use this to display the distance from the
different channels to the listening position. See
Speaker Distance on page 103 for more on this.
1
Select ‘Speaker Distance’ from the
MCACC Data Check menu.
2
When ‘MCACC’ is highlighted, use
/
to select the MCACC preset you want to
check.
The distance from the various channels set at
the selected MCACC preset is displayed. ‘
---’ is
displayed for channels that are not connected.
