22
EN
2
Po
w
e
r S
u
p
p
ly
Power Supply
2
Connect the AC cable to the AC
adapter and the AC adapter to the
household power supply outlet.
Recharging the battery
Connecting the recorder to the
▌
USB AC adapter for recharge
Inserting the battery
Use one Olympus lithium ion battery (LI-50B).
Other batteries are not supported.
1
Slide the lock switch to [OPEN] to
open the battery cover.
2
Insert the battery.
3
Close the battery cover.
• After closing the battery cover, slide
the lock switch to [LOCK].
1
Connect the USB cable to the USB
terminal of the AC adapter.
3
Connect the USB cable to the USB
terminal of the recorder.
• The PEAK display lamp (R) lights up in
orange and recharging starts.
• Insert the battery so that the direction
of the arrow (label) on the recorder
matches the direction of the arrow on
the battery.
