Little Board P6d Module
3-5
Table 3-1. Supported CRT Video Modes—Standard VGA
Video
Mode #
Pixel
Resolution
Color
Depth
Font
Size
Character
Resolution
Pixel Clock
(MHz)
Horizontal
Frequency
(KHz)
Vertical
Frequency
(Hz)
00h 360x400 16 9x16 40x25 25.175 31.4 70
01h 360x400 16 9x16 40x25 25.175 31.4 70
02h 720x400 16 9x16 80x25 25.175 31.4 70
03h 720x400 16 9x16 80x25 25.175 31.4 70
04h 320x200 4 8x8 40x25 28.322 31.5 70
05h 320x200 4 8x8 40x25 28.322 31.5 70
06h 640x200 2 8x8 80x25 25.175 31.4 70
07h 720x400 Mono 9x16 80x25 25.175 31.4 70
08h
--
0Ch
Reserved ---- ---- ---- ---- ---- ----
0Dh 320x200 16 8x8 40x25 25.175 31.4 70
0Eh 640x200 16 8x8 80x25 25.175 31.4 70
0Fh 640x350 Mono 8x14 80x25 25.175 31.4 70
10h 640x350 16 8x14 80x25 25.175 31.4 70
11h 640x480 2 8x16 80x30 25.175 31.4 60
12h 640x480 16 8x16 80x30 25.175 31.4 60
13h 320x200 256 8x8 40x25 25.175 31.4 70
