Little Board P6d Module
3-3
–
Software programmable flat panel interface. Flat panel video BIOS contained in an on-board
Flash EPROM device for easy customization.
–
Standard model supports 3.3V flat panels; support for 5V flat panels with external adapter.
–
Supports Zoom Video Port
! Ethernet LAN Interface
–
Complies with IEEE 802.3 (ANSI 8802-3) MII
–
Controller: Intel 82559ER 10/100Mbps Ethernet controller
–
Topology: Ethernet bus, using CSMA/CD
–
Plug and Play compatible
–
10/100BaseT via an on-board RJ45 connector
–
Data rate: automatic arbitration for 10/100Mbps operation
–
32-bit PCI host interface for fast operation, up to 33MHz PCI clock frequency (PCI specification
revision 2.1)
–
High-performance bus mastering capability
–
Boot ROM image can be installed in system using a Flash programming utility
Support Software
Ampro embedded PC-BIOS features:
! Watchdog timer (WDT) support
! Fail-safe boot logic
! Battery-free boot
! Serial console option
! Serial loader option
! EEPROM access functions
! Advanced Power Management (APM) support
! Large hard disk Logical Block Addressing (LBA) support
! See the Ampro Embedded-PC BIOS data sheet for additional details about these features.
Software Utilities included:
! Watchdog timer support
! Serial access and development support
! Display controller support
! Ethernet controller support
Mechanical and Environmental Specifications
146x203x30 mm (8.0x5.75x1.2”). Refer to Figure 2–1 for mounting dimensions.
Power requirements of 3.5A (typical, with 16MB DRAM, measured at 5V ± 5%). Power
requirements can vary, depending on the installed CPU and type of system DRAM installed.
Operating environment:
! Standard: 0 ° to 60 ° C (with adequate airflow)
! Extended temperature range of –40 ° to +85 ° C can be tested by special order. Contact Ampro
for more information.
