SWITCHING CHARACTERISTICS
•
Min / Max characteristics and specifications are guaranteed over all
Recommended Operating Conditions
•
Typical characteristics and specifications are measured at nominal supply voltages and TA = 25 °C.
•
VA+ = 5 V ±5% VD+ = 3.3 V ±5% or 5 V ±5%; AGND = DGND = 0 V. All voltages with respect to 0 V.
•
Logic Levels: Logic 0 = 0 V, Logic 1 = VD+.
Notes:
16.
Specified using 10% and 90% points on wave-form of interest. Output loaded with 50 pF.
17.
Oscillator start-up time varies with crystal parameters. This specification does not apply when using an external
clock source.
Parameter
Symbol Min Typ
Max
Unit
Rise Times
Any Digital Input Except SCLK
SCLK
Any Digital Output
t
rise
-
-
-
-
-
50
1.0
100
-
µs
µs
ns
Fall Times
Any Digital Input Except SCLK
SCLK
Any Digital Output
t
fall
-
-
-
-
-
50
1.0
100
-
µs
µs
ns
Start-up
Oscillator Start-Up Time
XTAL = 4.096 MHz (Note 17)
t
ost
-
60
-
ms
Serial Port Timing
Serial Clock Frequency
SCLK
-
-
2
MHz
Serial Clock
Pulse Width High
Pulse Width Low
t
1
t
2
200
200
-
-
-
-
ns
ns
SDI Timing
CS Falling to SCLK Rising
t
3
50
-
-
ns
Data Set-up Time Prior to SCLK Rising
t
4
50
-
-
ns
Data Hold Time After SCLK Rising
t
5
100
-
-
ns
SDO Timing
CS Falling to SDO Driving
t
6
-
20
50
ns
SCLK Falling to New Data Bit (hold time)
t
7
-
20
50
ns
CS Rising to SDO Hi-Z
t
8
-
20
50
ns
Auto-Boot Timing
Serial Clock
Pulse Width Low
Pulse Width High
t
9
t
10
8
8
MCLK
MCLK
MODE setup time to RESET Rising
t
11
50
ns
RESET rising to CS falling
t
12
48
MCLK
CS falling to SCLK rising
t
13
100
8
MCLK
SCLK falling to CS rising
t
14
16
MCLK
CS rising to driving MODE low (to end auto-boot sequence).
t
15
50
ns
SDO guaranteed setup time to SCLK rising
t
16
100
ns
