3-1 Copyright 2008 Cirrus Logic DS705RD3
Installation, Setup, and Running First Application
CRD49530-USB User’s Manual
Chapter 3
Installation and Setup for Running Application
3.1 Installation, Setup, and Running First Application
It is important to install the latest Evaluation Software ( cs4953x_eval_kit.exe)
BEFORE connecting the USB cable from the PC to the CRD Master-USB daughter
card. Failure to install the evaluation software before the initial connection can result in
an inability to communicate with the CRD49530.
3.1.1 Evaluation Software Installation
The DSP evaluation software installation will first install the Cirrus Logic DSP evaluation software followed
by the USB drivers required to communicate with the CRD USB Master.
1. Run the latest DSP evaluation software installation executable ( cs4953x_eval_kit_rcxx.exe .
This executable is supplied by your Cirrus Logic representative.
2. At the Welcome screen, click Next.
3. At the Licensing Agreement window, select the “I accept the agreement” radio button to agree to the
terms and then select Next.
4. Select the Destination Location window, Select the default location “C:\CirrusDSP” and click Next.
5. Select Start Menu Folder window, Select the default location “C:\CirrusDSP” and click Next.
6. The Ready to Install window indicates the selected destination location and the Start menu folder for
confirmation, select Install to begin the install process which should take less than one minute.
7. After the DSP evaluation software is installed, the installer will launch the Front Panel Driver Setup
Wizard (below). Click Next to continue the installation.
