CS4244
DC ELECTRICAL CHARACTERISTICS
GND = 0 V; all voltages with respect to ground.
Notes:
7. No external loads should be connected to the VDREG pin. Any connection of a load to this point may
result in errant operation or performance degradation in the device.
Parameters Min Typ Max Units
VDREG (Note 7)
Nominal Voltage
Output Impedance -
- 2.5
0.5 -
- V

FILT+
Nominal Voltage
Output Impedance
DC Current Source/Sink
-
-
- VA
23
-
-
-
1
V
k 
A
VQ
Nominal Voltage
Output Impedance
DC Current Source/Sink
-
-
- 0.5•VA
77
-
-
-
0
V
k 
A
