DS900F1
46
CS4244
16h
Volume
Mode
MUTE DELAY[1:0]
MIN DELAY[2:0]
MAX DELAY[2:0]
1
0 0 0 0 1 1 1
17h
Master
Volume
MASTER VOLUME[7:0]
0
0 0 1 0 0 0 0
18h
DAC1
Volume
DAC1 VOLUME[7:0]
0
0 0 1 0 0 0 0
19h
DAC2
Volume
DAC2 VOLUME[7:0]
0
0 0 1 0 0 0 0
1Ah
DAC3
Volume
DAC3 VOLUME[7:0]
0
0 0 1 0 0 0 0
1Bh
DAC4
Volume
DAC4 VOLUME[7:0]
0
0 0 1 0 0 0 0
1Ch
Reserved
Reserved[7:0]
0
0 0 1 0 0 0 0
1Dh
Reserved
Reserved[3:0] Reserved[3:0]
1
0
1
1 1 0 1 0
1Eh
Interrupt
Control
INT MODE
INT PIN[1:0]
Reserved
Reserved
Reserved
Reserved
Reserved
0
1 0 0 0 0 0 0
1Fh
Interrupt
Mask 1
MASK
TST MODE
ERR
MASK
SP ERR
MASK
CLK ERR
Reserved
MASK
ADC4 OVFL
MASK
ADC3 OVFL
MASK
ADC2 OVFL
MASK
ADC1 OVFL
0
0 0 1
0 0 0 0
20h
Interrupt
Mask 2
Reserved
Reserved
Reserved
Reserved
MASK
DAC4 CLIP
MASK
DAC3 CLIP
MASK
DAC2 CLIP
MASK
DAC1 CLIP
0
0
1
0 0 0 0 0
21h
Interrupt
Notification 1
TST MOD
E
SP ERR
CLK ERR
Reserved
ADC4 OVFL
ADC3
OVFL ADC2
OVFL ADC1
OVFL
x
x x x x x x x
22h
Interrupt
Notification 2
Reserved
Reserved
Reserved
Reserved
DAC4 CLIP DAC3
CLIP DAC2
CLIP DAC1
CLIP
x
x x x x x x x
AD
Function
7
6 5 4 3 2 1 0
(Read Only Bits are shown in Italics)
