Page 19
DS900F1
19
CS4244
SWITCHING CHARACTERISTICS - SERIAL AUDIO INTERFACE
= 0 for VA = 3.3 VDC, 1 for VA = 5.0 VDC.
Notes:
25. After applying power to the
CS4244
,
RST
should be held low until after the power supplies and MCLK
are stable.
26. MCLK must be synchronous to and scale with F
S
.
27. The SCLK frequency must remain less than or equal to the MCLK frequency. For this reason, SCLK
may range from 256x to 512x only in single speed mode. In double speed mode, 256x is the only ratio
supported.
28. The MSB of CH1 is always aligned with the second SCLK rising edge following FS/LRCK rising edge.
29. Where “n” is equal to the MCLK to LRCK ratio (set by the
register bits), i.e. in 256x
mode, n = 256, in 512x mode, n = 512, etc.
Parameters Symbol
Min
Max
Units
RST
pin Low Pulse Width
1
-
ms
MCLK Frequency
7.68
25.6
MHz
MCLK Duty Cycle
45
55
%
SCLK Duty Cycle
45
55
%
Input Sample Rate (FS/LRCK pin)
Single-Speed Mode
Double-Speed Mode
F
S
F
S
30
60
50
100
kHz
kHz
SCLK Falling Edge to SDOUTx Valid (VL = 1.8 V)
t
dh2
-
31
ns
SCLK Falling Edge to SDOUTx Valid (VL = 2.5 V)
t
dh2
-
22
ns
SCLK Falling Edge to SDOUTx Valid (VL = 3.3 V or 5 V)
t
dh2
-
17
ns
TDM Slave Mode
SCLK Frequency
256x
512x
F
S
FS/LRCK High Time Pulse
t
lpw
1/f
SCLK
(n-1)/f
SCLK
ns
FS/LRCK Rising Edge to SCLK Rising Edge
t
lcks
5
-
ns
SDINx Setup Time Before SCLK Rising Edge
t
ds
3
-
ns
SDINx Hold Time After SCLK Rising Edge
t
dh1
5
-
ns
PCM Slave Mode
SCLK Frequency
32x
64x
F
S
FS/LRCK Duty Cycle
45
55
%
FS/LRCK Edge to SCLK Rising Edge
t
lcks
5
-
ns
SDINx Setup Time Before SCLK Rising Edge
t
ds
3
-
ns
SDINx Hold Time After SCLK Rising Edge
t
dh1
5
-
ns
PCM Master Mode
SCLK Frequency
64x
64x
F
S
FS/LRCK Duty Cycle
45
55
%
FS/LRCK Edge to SCLK Rising Edge
t
lcks
5
-
ns
SDINx Setup Time Before SCLK Rising Edge
t
ds
5
-
ns
SDINx Hold Time After SCLK Rising Edge
(VL = 1.8 V)
t
dh1
11
-
ns
SDINx Hold Time After SCLK Rising Edge
(VL = 2.5 V, 3.3 V, or 5 V)
t
dh1
10
-
ns
