NEXT>>>ADVANCE www.nextadvance.com
SP1600/1800 Programmable Syringe Pump
Publication #1200-02 52 9/15/04
11.6 Specifications
11.6.1 Mechanical & Electrical
Syringe sizes:
SP1600 Up to 140 cc
SP1800 Up to 10 cc
Number of syringes:
SP1600 6
SP1800 8
Motor type: Step motor
Motor steps per revolution: 200
Microstepping: 1/8 to 1/4 depending on motor speed
Advance per microstep: 0.132291667 to 0.264583333 uM depending on motor speed
Motor to drive screw ratio: 5/1
Drive screw pitch: 24 revolutions/”
DC connector: 2.5 mm, center positive
Voltage at DC connector: 12V DC at full load
Amperage: 1000 mA at full load
Power supply type: Unregulated linear external wall adapter, country and power
source specific
Power supply output rating: 12V DC @ 1000 mA
Dimensions: 10 1/4” x 15” x 5” High
(26.035 cm x 38.1 cm x 12.7 cm)
Weight: 10.125 lbs. (4.595 kg)
11.6.2 Operational
Maximum speed: 3.3327 cm/min
Minimum speed: 0.0262 cm/hr
Maximum pumping rate: 1110 ml/hr with a B-D 60 cc syringe
Minimum pumping rate: 4.532 l/hr with a B-D 1 cc syringe
Force applied to all syringes: 160 lbs. at minimum speed, 30 lbs. at maximum speed
Number of Program Phases: 41
RS-232 pump network: 100 pumps maximum
RS-232 selectable baud rates: 300, 1200, 2400, 9600, 19200
Syringe inside diameter range: 0.100 to 50.00 mm
11.7 Custom Applications
For specialized and OEM applications, contact your dealer
or Next Advance Inc. Custom modifications can be made
to the mechanics or the firmware.
