SP1000 series operator’s manual
Manual SP1000 series 52
12.5 Specifications
12.5.1 Mechanical & Electrical
Syringe sizes: Up to 60 mL (140 mL partially filled)
Number of syringes: 1
Motor type: Step motor
Motor steps per revolution: 400
Microstepping: 1/8 to 1/2 depending on motor speed
Advance per step: 0.2126 uM to 0.8504 uM depending on motor speed
Motor to drive screw ratio: 15/28
Drive screw pitch: 20 revolutions/”
DC connector: 2.1 mm, center positive
Voltage at DC connector: 12V DC at full load
Amperage: 750 mA at full load
Power supply type: Unregulated linear external wall adapter, country and power
source specific
Power supply output rating: 12V DC @ 800 mA
Dimensions: 8 3/4” x 5 3/4” x 4 1/2” High
(22.86 cm x 14.605 cm x 11.43 cm)
Weight: 3.6 lbs. (1.63 kg)
Allen Wrench 3/32 Hex
12.5.2 Operational
Maximum speed: 5.1005 cm/min
Minimum speed: 0.004205 cm/hr
Maximum pumping rate: 1699 ml/hr with a B-D 60 cc syringe
Minimum pumping rate: 0.73 l/hr with a B-D 1 cc syringe
Maximum force: 35 lbs. at minimum speed, 18 lbs. at maximum speed
Number of Program Phases: 41
RS-232 pump network: 100 pumps maximum
RS-232 selectable baud rates: 300, 1200, 2400, 9600, 19200
Syringe inside diameter range: 0.100 to 50.00 mm
12.6 Custom Applications
For specialized and OEM applications, contact Next
Advance Inc. Custom modifications can be made to the
mechanics or the firmware.
