QLS-4100 X
36
Calibrating Reflective Media
Lift each of the printheads for this calibration routine in order to conserve ribbon.
Disengage the drive roller by turning the Drive Roll Lift Lever clockwise.
Position the reflective mark so that the red light from the reflective sensor passes
through the mark. The light will typically pass through most media allowing you to
view the mark from above. On more opaque media, you may have to view the
mark from the bottom.
Engage the drive roller by turning the Drive Roll Lift Lever counterclockwise.
Press the PRINT/PAUSE key until the printer display shows Pause on the display.
Press PREV or NEXT key until the Calibrate menu is displayed.
Press the + or - key until Reflective is displayed.
Press the SELECT key. The display will show the following prompt:
Press the SELECT key again. The display will show the following prompt:
Reposition the media by pressing and holding the FORM FEED/ADVANCE key
until the red light no longer shines through the mark but through the media.
Place Mark @ Sensor
Then Press Select
1
2
3
4
5
6
7
8
9
Place Media @ Sensor
Then Press Select
Pause: Calibrate
Reflective
*
