Astro Pneumatic 78444 44pc Master Radio Removal Set - Manual

Call 1.800.221.9705 for questions concerning performance of the product
or other inquiries.
Page 2
78444
372 Old US Highway 52 South
Mount Airy, NC 27030
Page 1
78444
Important
When unpacking, check the parts diagram and part number
listing on page 2 to make sure all parts are included. If any
parts are missing or damaged, please call your distributor.
Unpacking
www.astrotools.com
Product Information
•Astro Pneumatic Tool Co. warrants our products to the original user against
defective material or workmanship for a period of 1 year from the date of 1st use.
Astro reserves the right to determine whether the product failed because of defective
material, workmanship or other causes and to charge back for missing parts. Astro
Pneumatic Tool Co., at its discretion, will repair products covered under this warranty
free of charge. The original user is to return the product (with the exceptions listed
below) with the distributor’s name, address, adequate proof of date of purchase or a
copy of warranty card, and a short note explaining the problem. Failures caused
by accident, alteration, or misuse are not covered by this warranty.
•
If one part of this product fails, please do not return the entire product.
Astro will replace free of charge component parts of this product that fail
within 1 year of first use by the original user. Items included in this category
include but are not limited to kits, hand tool kits and any other product where
there are multiple items or components that make up the unit. Please contact
the phone number below in order to obtain the replacement components
covered under warranty.
•Astro Pneumatic Tool Co. or its authorized service representatives must perform all
warranty repairs. Any repair to the product by unauthorized service representatives
voids this warranty. The rights under this warranty are limited to the original user
and may not be transferred to subsequent owners.
•This warranty is in lieu of all other warranties, expressed or implied, including
warranties of merchantability and fitness for a particular purpose. Some states do
not allow the exclusion of limitations of incidental or consequential damages so the
above limitations may not apply to you. All claims must be sent to:
Astro Pneumatic Tool Company
372 Old US Highway 52 South
Mt. Airy, NC 27030
1 YEAR LIMITED WARRANTY
PLEASE CALL 1-800-221-9705
FOR REPAIR AND RETURN INSTRUCTIONS
44
PC.
MASTER RADIO REMOVAL SET
44
PC.
MASTER RADIO REMOVAL SET
44
PC.
MASTER RADIO
REMOVAL SET
Product: 78444 Manual
Dimension: 8.5”x 11”/page
Date: 2007/01/22
Color:
Black
• Set includes the following tools needed to install and remove radios:
2 - Radio Removal U-Hooks (Ford/VW/Audi/Grundig/Blaupunkt)
1 - Special Pentagon Wrench (BMW)
4 - Radio Removal Keys (VW/Audi/Becker/Mercedes-Benz)
2 - Radio Removal Keys (Mercedes-Benz/Porsche/Becker)
2 - Radio Removal Keys (VW)
1 - Allen Hex Wrench (BMW/Opel)
2 - Radio Removal U-Hooks (New Blaupunkt)
6 - Radio Removal Keys (Mercedes-Benz/BMW)
2 - Radio Removal Keys (Kenwood II 1998-2001)
2 - Radio Removal Keys (Sony II ab 2002)
2 - Radio Removal Keys (Kenwood III ab 2002)
2 - Radio Removal Keys (Pioneer & JVC)
2 - Radio Removal Keys (Sony I bis 2005)
2 - Radio Removal Keys (Panasonic)
2 - Radio Removal Keys (Kenwood I bis 1998)
2 - Radio Removal Keys (Kenwood MASK)
2 - Radio Removal Keys (Clarion-New)
2 - Radio Removal Keys (Clarion (ALT))
2 - Radio Removal Keys (Panasonic 2006)
2 - Radio Removal Keys (Sony IDIC 2005)
78444-01
78444-02
78444-03
78444-04
78444-05
78444-06
78444-07
78444-08
78444-09
78444-10
78444-11
78444-12 Radio Removal Keys (Kenwood II 1998-2001)
Radio Removal Keys (Sony II AB 2002)
Radio Removal Keys (Kenwood II AB 2002)
Radio Removal Keys (Sony I bis 2001)
Radio Removal Keys (Kenwood I bis 1998)
Radio Removal Keys (Panasonic 2006)
Radio Removal Keys (Panasonic)
Radio Removal Left Key (Kenwood Mask)
Radio Removal Right Key (Kenwood Mask)
Radio Removal Keys (Clarion-New)
Radio Removal Keys (Clarion (ALT))
Radio Removal Keys (Mercedes-Benz & BMW) 2
2
2
2
2
2
2
1
1
2
2
2 1
2
3
4
5
6
7
8
9
10
11
12
Index
No.
78444-13
78444-14
78444-15
7807-03L
7807-03R
7807-04
7807-05
7807-08
7807-01
78444-22
7807-02
7807-09 Radio Removal Keys (Mercedes-Benz & BMW)
Radio Removal Keys (Sony I Bis 2005)
Radio Removal Keys (Mercedes-Benz & BMW)
Radio Removal Left Key (VW/Audi/Becker/Mercedes-Benz)
Radio Removal Right Key (VW/Audi/Becker/Mercedes-Benz)
Radio Removal Keys (Becker/Porsche/Mercedes-Benz)
Radio Removal Keys (VW)
Radio Removal U-Hooks (Ford/VW/Audi/Grundig/Blaupunkt)
Radio Removal U-Hooks (New Blaupunkt)
Radio Removal Keys (Pioneer & JVC)
Special Pentagon Wrench (BMW)
Allen Hex Wrench (BMW/Opel) 2
2
2
2
2
2
2
2
2
2
1
1 13
14
15
16
17
18
19
20
21
22
23
24
Index
No.
