Page 1

7801

When unpacking, check the parts diagram and part number
listing on page 3 to make sure all parts are included. If any
parts are missing or damaged, please call your distributor.

Unpacking

www.astrotools.com

7pc. SENSOR &

SENDING UNIT SOCKET SET

PLEASE DO NOT RETURN ANY PRODUCT WITHOUT CALLING

1-800-221-9705 FOR INSTRUCTIONS

MADE IN CHINA

7pc. SENSOR & SENDING UNIT SOCKET SET

• Astro Pneumatic Tool Co. warrants our products to the original user against defective

material or workmanship for a period of 1 year (except where noted on our price

schedule) from the date of 1st use. Astro reserves the right to determine whether the

product failed because of defective material, workmanship or other causes and to charge

back for missing parts. Astro Pneumatic Tool Co., at its discretion, will repair products

covered under this warranty free of charge. The distributor should direct the original user

to return the product (with the exceptions listed below) with the distributor’s name,

address, adequate proof of date of purchase or a copy of warranty card, and a short note

explaining the problem.

Failures caused by accident, alteration, or misuse are not

covered by this warranty.

• If one part of this product fails, please do not return the entire product. Astro will

replace free of charge component parts of this product that fail within 1 year of first

use by the original user. Items included in this category include but are not limited

to kits, hand tool kits and any other product where there are multiple items or

components that make up the unit. Please contact the phone number below in

order to obtain the replacement components covered under warranty.
• Astro Pneumatic Tool Co. or its authorized service representatives must perform all

warranty repairs. Any repair to the product by unauthorized service representatives

voids this warranty. The rights under this warranty are limited to the original user and may

not be transferred to subsequent owners.

• This warranty is in lieu of all other warranties, expressed or implied, including warranties

of merchantability and fitness for a particular purpose. Some states do not allow the

exclusion of limitations of incidental or consequential damages so the

above limitations may not apply to you.

1 YEAR LIMITED WARRANTY

PRODUCT INFORMATION:

IMPORTANT

• Oil Pressure Sending Unit Socket ½" Dr. x 29mm x 90mm

- Allows the removal of oil pressure sending units on late

1980 and mid 1990 GM vehicles.

- Designed to be used with 1/2" drive tool.
• Oxygen Sensor Socket 3/8" Dr. x 7/8" (22mm) x 90mm

- Designed to remove and install vacuum switches with a 7/8" hex

and some oxygen sensors.

- Designed to be used with 3/8" drive tool or with a 1" wrench.
• Injector Socket 1/2" Dr. x 1-1/16" (27mm) x 85mm

- Allows the removal and installation of thermal sensor switch on

1973 - 1977 GM vehicles.

- Designed to be used with 1/2" drive tool.
• Vacuum Switch Socket 3/8" Dr. x 7/8" (22mm) x 80mm

- Designed to remove and install oxygen sensors in most domestic

and many imported vehicles.

- Socket designed with slot which allows clearance of wire.

- Designed to be used with a 3/8" drive tool or 1" wrench.

Oil Pressure Sending Unit Socket 3/8" Dr. 1" & 1-1/16" (27mm) x 74mm

- Includes a 1" and 1-1/16" hex which allows the removal of

oil pressure sending units.

- Special deep design fits switches up to 2-5/8".

- Designed to be used with a 3/8" drive tool or 1-1/8" wrench
• Heated Oxygen Sensor Socket 1/2" Dr. x 7/8" (22mm) x 50mm

- Socket designed with slot in socket which accommodates the

connectors on heat oxygen sensors.

- Socket has a double 1/2" drive for easy access.
• Low Profile Offset Oxygen Sensor Socket 3/8" Dr. x 7/8" (22mm) x 30mm

- Low profile design for use in tight spaces.

- Designed to be used with 3/8" drive tool.
