Connecting the VS-812 8x1 Composite / s-Video / Audio Switcher
6
6. Connecting the VS-812 8x1 Composite / s-Video / Audio
Switcher
To connect
1
Figure 2 the VS-812, as illustrated in the example in , do the
following
2
1. Connect up to eight composite video and stereo audio
:
3
sources (for example,
composite video players) to the IN BNC connectors and terminal block
4
2. Connect up to eight s-Video and stereo audio sources (for example, s-Video
players) to the IN 4-pin connectors and terminal block connectors
connectors.
4
.
3. Connect the two OUT BNC connectors to up to two composite video acceptors
(for example, composite video recorders)
4. Connect the two OUT 4-pin connectors to up to two s-Video (Y/C) acceptors
(for example, s-Video recorders).
5. Connect the two OUT terminal block connectors
4
to up to two balanced stereo
audio acceptors (for example, balanced stereo audio amplifiers with speakers).
6. If required, you can connect a PC and/or controller to the RS-232 port.
7. Connect the power cord
4,5
.
1 You do not need to connect all inputs and outputs
2 Switch OFF the power on each device before connecting it to your VS-812. After connecting your VS-812, switch on its
power and then switch on the power on each device
3 Balanced or unbalanced (see section 6.1 )
4 Not shown in Figure 2
5 We recommend that you use only the power cord that is supplied with this machine
