VP-771 - The VP-771 RS-232 Communication Protocol 71
71
1st
Level
2nd Level 3rd Level 4th Level Range Func. Note
Temporal NR 0:3 533
Block NR 0:3 534 unavailable in
progressive scan
Scale Aspect Ratio Follow input 0 610 1. Single window
only
2. Customization lost
3. In “Follow Input”,
output must be
bigger than input
Follow Output 1
Best Fit 2
Letterbox 3
Overscan Off 0 620
5% 1
10% 2
Output Video Resolution Native 0 631 1. GET command in
native mode returns
the determined
resolution of the
master connection
2. Special OSD
MENU screen,
follow OSD
instructions
640x480@60 1
640x480@75 2
800x600@50 3
800x600@60 4
800x600@75 5
1024x768@50 6
1024x768@60 7
1024x768@75 8
1280x768@50 9
1280x768@60 10
1280x800@60 11
1280x1024@50 12
1280x1024@60 13
1280x1024@75 14
1360x768@60 15
1366x768@50 16
1366x768@60 17
1400x1050@50 18
1400x1050@60 19
1600x900@60 20
1600x1200@50 21
1600x1200@60 22
1680x1050@60 23
1920x1200@60 24
480i60 25
480p60 26
576i50 27
576p50 28
720p50 29
720p59.94 30
720p60 31
1080p23.976 32
1080p24 33
1080p25 34
1080p29.97 35
