52 VP-771 - Controlling the VP-771
8.3.2 Connecting to the VP-771 via RS-232
You can connect to the VP-771 via an RS-232 connection using, for example, a PC.
Note that a null-modem adapter/connection is not required.
To connect to the VP-771 via RS-232, connect the RS-232 9-pin D-sub rear panel
port on the VP-771 unit via a 9-wire straight cable (only pin 2 to pin 2, pin 3 to pin 3,
and pin 5 to pin 5 need to be connected) to the RS-232 9-pin D-sub port on your PC.
8.3.3 Connecting the VP-771 via the ETHERNET Port
You can connect the VP-771 via the Ethernet, using a crossover cable
(see Section 8.3.3.1 ) for direct connection to the PC or a straight through cable
(see Section
8.3.3.2
) for connection via a network hub or network router.
8.3.3.1 Connecting the ETHERNET Port directly to a PC (Crossover Cable)
You can connect the Ethernet port of the VP-771 to the Ethernet port on your PC,
via a crossover cable with RJ-45 connectors.
This type of connection is recommended for identification of the factory
default IP Address of the VP-771 during the initial configuration.
After connecting the Ethernet port, configure your PC as follows:
1. Right-click the My Network Places icon on your desktop.
2. Select Properties.
3. Right-click Local Area Connection Properties.
4. Select Properties.
The Local Area Connection Properties window appears.
5. Select the Internet Protocol (TCP/IP) and click the Properties Button (see
Figure 32 ).
