# Feature Function
36 DISPLAYPORT Connect to the DisplayPort source
37 SDI IN Connect to the SDI source
38 SDI LOOP Connect to a local display
39
VIDEO
OUTPUT
Connectors
PC 15-pin HD Connect to a computer graphics acceptor
40 SDI BNC Connect to an SDI acceptor
41 HDMI Connect to an HDMI acceptor
42 DGKAT RJ-45 Connect to a DGKat receiver (for example, Kramer PT-572+)
43 RS-232 9-pin D-sub Port Connect to the PC or other serial controller
44 ETHERNET Connector Connects to the PC or other Controller through computer networking
45 REMOTE Terminal Block Connectors For remotely switching the inputs and PIP input via contact closure switches
46 Power Connector with Fuse AC connector, enabling power supply to the unit
47 POWER Switch Switch for turning the unit ON or OFF
