6. Connect the audio input signals to the AUDIO IN connectors (3.5mm mini
jack and RCA connectors), as required (not shown in Figure 4 ).
7. Connect an SDI source (for example, an SDI digital camera) to the SDI IN
BNC connector.
8. Connect the SDI LOOP BNC connector to an SDI monitor (for example, an
SDI display).
9. Connect the PC VIDEO OUTPUT 15-pin HD connector to a VGA acceptor
(for example, an analog display).
10. Connect the SDI VIDEO OUTPUT BNC connector to an SDI acceptor (for
example, an SDI display with speakers).
11. Connect the HDMI VIDEO OUTPUT connector to an HDMI acceptor (for
example, a plasma display).
12. Connect the DGKAT RJ-45 connector to a receiver (for example, the Kramer
PT-572+).
13. Connect the SPKR block connector to a pair of loudspeakers, by connecting
the left loudspeaker to the “L+” and the “L-” terminal block connectors, and
the right loudspea ker to the “R+” and the “R-” terminal block connectors. Do
not Ground the loudspeakers (not shown in Figure 4 ).
14. If required, you can connect a PC and/or controller to the:
 RS-232 terminal block (see Section 8.3.2 )
 Ethernet connector (see Section 8.3.3 )
15. Connect the power cord (not shown in Figure 4 ).
