8.5 Additional Inputs / Outputs
⇒ Read Motor Input Channels and additional Inputs
The analogue channels are prepared for ratiometric measurements of resistive dividers. Channel 6 is
the external input, channel 7 measures the voltage supply of the PACK (1V equals value 22). The
reference inputs are inverted.
CMD $30
P0 channel no (0=channel0 ... 7=channel7).
P1 response address
Response
CMD $30
P0
channel no (0...7).
P1,2 # analogue value (unsigned 0..1023)
P3 reference input (Bit 0)
P4 all reference inputs / jumpers (bit 0 = motor 0, ..., bit 6=jumper1, bit 7 = jumper2)
(s. setting the baud rate)
P5 bit 0: logic state at TTLIO1
⇒ Setting the Limits for the Stop Function left/right
A potentiometer or a resistor network connected to two stop switches at the analogue input of each
motor can trigger a hard or soft stop. The voltage of the analogue input should increase in right
direction (cw). The measured value is checked dependent on the motor direction. When a stop-
condition occurs the motor is stopped immediately. If StopSoft-Flag is set, the motor is in decelerated
with the pre-set acceleration. If the StopSoft Flag isn’t set the motor will be stopped abruptly, so that
the precise motor position may be lost. Therefore a reference search will be started additionally if the
StopNoRef-Flag is not set. When the StopNull-Flag is set, the zero switch also functions as a limit
switch. If the reference switch is defined on the right side, the motor then can only drive in the area of
negative co-ordinates
(position <= 0) (s. CMD $15)
CMD $31
P0 channel no (0...7):
P1,2 # analogue value minimum for stop left (0=no function)
P3,4 # analogue value maximum for stop right ( ≥1023=no function)
⇒ Setting of additional Outputs
CMD $32
P0 bit 0: set logic level at TTLOUT1 (1=READY, 0= active)
P1 bit 0: output enable for TTLIO1 (1=input, 0=output)
P2 bit 0: set logic level at TTLIO1
P3 bit 0: 1=TTLOUT1 works as ready output (1=READY, 0= active)
