Example for a test - setup, Further information, C o n t r o l – RMS Technologies 4-AXIS CONTROLLER/DRIVER User Manual
Page 12: 7 example for a test - setup, 8 further information
12
S I X P A C K / Q U A D P A C K
Trinamic Motion Control GmbH & Co KG
Sternstraße 67
D – 20357 Hamburg, Germany
Phone +49-40-51 48 06 - 0
FAX: +49-40-51 48 06 - 60
http://www.trinamic.com
5.7 Example for a TEST - Setup
5.8 Further
Information:
For further Information please view our homepage (www.trinamic.com). You will find help under
“frequently asked questions”. You also have the possibility to send us an e-mail via a contact sheet
located on the same site.
SIX- / QUADPack
RS232 - Cable
PC / uC
Power Supply
DC
15 - 40V
M
PHA1
PHA2
PHB1
PHB2
5V
Ref_in
A_in
