Link-RX/TX ( 10 / 100 ) LED
This LED indicates the network status.
Status LEDs
These LEDs indicate the Management Card’s status.
Condition Description
Off Either the Management Card is receiving no network traffic, or the
device which connects the Management Card to the network is
turned off or not operating correctly.
Flashing Green The Management Card is receiving data packets from the network
at 10 Megabits per second (Mbps).
Flashing Orange The Management Card is receiving data packets from the network
at 100 Megabits per second (Mbps).
Condition Description
Off The Management Card has no power.
Solid Green The Management Card has valid TCP/IP settings.
Flashing Green The Management Card does not have valid TCP/IP settings.
1
Solid Orange A hardware failure has been detected in the Management Card.
Contact
APC Worldwide Customer Support .
Flashing Orange The Management Card is making BOOTP
2
requests.
1.If you do not use a BOOTP server, see the Network Management Card Quick-Start Manual
(.\doc\en\Qckguide) provided in printed format and in PDF on the APC Network Management
Card utility CD
for information about how to configure the Management Card’s TCP/IP
settings.
2.To use a BOOTP server, see the Management Card Addendum (.\doc\Addendum.pdf) on the
APC Network Management Card utility CD.
