USER’S GUIDE
network management card
10
To connect Type 2 equipment:
1. Select a serial port at the local computer, and disable any service that
uses that port.
2. Use the smart-signaling (advanced signaling) cable (940-0024 or
940-1524) to connect the selected port to the serial port on the
mounting bracket of the Management Card.
To continue the procedure for either type of equipment:
3. Run a terminal program (such as HyperTerminal
®
), and configure the
selected port for 2400 bps, 8 data bits, no parity, 1 stop bit, and no flow
control, and save the changes.
4. Press
E
NTER
to display the
User Name
prompt.
5. Enter your user name and, at the
Password
prompt, your password.
Do not attach the cable to the serial port on the front panel of
the DC System Controller
