USER’S GUIDE
network management card
44
Management Options
DC Power Plant options
Control Console and Web Interface. To access the following menu
options to manage the DC Power Plant:
• In the control console, select Device Manager and DC Power Plant .
• In the Web interface, use the menus in the top section of the navigation
panel.
Control Console Web interface Link to Description
1 - DC System System > DC
Parameters
DC System: DC System
Parameters & OEM Parameters
2 - Power Modules Power Modules Power Modules: Rectifiers and
Converters
3 - Distribution Distribution Distribution: Breakers and Fuses
4 - Batteries Batteries>Parameters Batteries: Status, Thresholds and
Alarms
5 - Relays I/O Relays: Output Relays and Input
Relays
6 - LVD Batteries>LVD LVD (Low Voltage Disconnect)
7 - Power Plant
Alarms/
Internal Log
System>Active
Alarms
(Internal Log
not available)
Power Plant Alarms/Internal Log
8 - About DC
Power System
not available About DC Power Plant System
In the Web interface, you display Power Plant alarms by
selecting
Active Alarms from the first menu ( System ) in the
navigation panel.
