AIMB-221 User Manual

40

2.19

FPAUD1

FPAUD1

pin.1

FP_MIC_IN1

pin.2 GND

pin.3 MIC_VREF

pin.4

VCC

pin.5 REAR_LO_R

pin.6

LINEOUT_R

pin.7

NC

KEY

pin.9 REAR_LO_L

pin.10 LINEOUT_L
