29 AIMB-221 User Manual
Chapter 2
C
onnecting
Peripherals
The mainboard provides a 26-pin header for connection to an optional parallel port
bracket. The parallel port is a standard printer port that supports Enhanced Parallel
Port (EPP) and Extended Capabilities Parallel Port (ECP) mode.
LPT1
pin.1 LTP1_#STBB pin.2 LTP1_#AFD
pin.3 LTP1_PD0B pin.4 LTP1_#ERR
pin.5 LTP1_PD1B pin.6 LTP1_#INIT
pin.7 LTP1_PD2B pin.8 LTP1_#SLIN
pin.9 LTP1_PD3B pin.10 GND
pin.11 LTP1_PD4B pin.12 GND
pin.13 LTP1_PD5B pin.14 GND
pin.15 LTP1_PD6B pin.16 GND
pin.17 LTP1_PD7B pin.18 GND
pin.19 LTP1_#ACK pin.20 GND
pin.21 LTP1_BUSY pin.22 GND
pin.23 LTP1_PE pin.24 GND
pin.25 LTP1_SLC KEY -
