3 AIMB-221 User Manual
Chapter 1
H
ardware
C
onfiguration
1.3 Specifications
1.3.1 System
! CPU: AMD S1g1 Turion 64X2 Dual Core and Mobile Sempron processor up to
2.1/2.0 GHz, HT 800 MHz. Advantech also certifies several optional high-perfor-
mance CPU coolers for high-speed CPUs in 2U chassis or in high-temperature
environments.
! L2 Cache: CPU has one of the following built-in full-speed L2 caches
1 MB for AMD Turion 64X2 TL-62 and TL56 CPUs,
512 KB for Mobile AMD Sempron 3700 + CPUs, and
256 KB for Mobile AMD Sempron 2100 + CPUs.
! BIOS: Award 16 Mbit LPC
! System Chipset: AMD M690T/M690E with SB600
! SATA hard disk drive interface: Four on-board SATA2 connectors support
Advanced Host controller interface (AHCI) technology and have data transmis-
sion rates up to 300 MB/s.
! One on-board IDE connector: Supports PIO mode 4 (16.67 MB/s) and ATA
33/66/100 (33/66/100 MB/s) BIOS enabled/disabled.
1.3.2 Memory
! RAM: Up to 4 GB in two 200-pin SO-DIMM sockets. Supports dual-channel
DDRII 533/667/800 SDRAM.
Note! Advantech offers one CPU Cooler in the standard package. This cooler
is capable of keeping the temperature of 35 W-thermal-spec CPUs
within specification under the environmental temperatures of 55° C with-
out a chassis or 40° C with a chassis.
Note! Due to limitations of the PC architecture, the system may NOT fully
detect 4 GB of RAM when 4 GB of RAM is installed.
