2.18

Audio

AUDIO1

pin.A1

GND

pin.A2

MIC_IN2

pin.A3 NC

pin.A4 NC

pin.A5

MIC_IN1

pin.B2

LINEOUT_L

pin.B3 NC

pin.B4 NC

pin.B5 LINEOUT_R

pin.C2

LINEIN_L

pin.C3 NC

pin.C4 NC

pin.C5 LINEIN_R
