Format
Number
Card Read
Mode
CSN
Wiegand
Output Mode
Beeper/LED Configuration
Keypad Output
(if applicable)
Equivalent FlexSmart
Part Suffix
02FM-0281
CSN Only
32 bit MSB
Beep OFF, Left LED normally
OFF, Right LED GREEN on
read on read
4-bit
607xAKN 03 1 1 0 0
02FM-0282
CSN Only
32 bit MSB
Beep OFF, Left LED normally
OFF, Right LED GREEN on
read on read
8-bit
607xAKN 03 1 1 0 9
02FM-0245
CSN Only
32 bit MSB
Beep OFF, Left LED normally
RED, Right LED GREEN on
read on read
4-bit
607xAKN 01 1 1 0 0
02FM-0246
CSN Only
32 bit MSB
Beep OFF, Left LED normally
RED, Right LED GREEN on
read on read
8-bit
607xAKN 01 1 1 0 9
02FM-0263
CSN Only
32 bit MSB
Beep ON, Left LED normally
OFF, Right LED GREEN on
read on read
4-bit
607xAKN 02 1 1 0 0
02FM-0264
CSN Only
32 bit MSB
Beep ON, Left LED normally
OFF, Right LED GREEN on
read on read
8-bit
607xAKN 02 1 1 0 9
02FM-0227
CSN Only
32 bit MSB
Beep ON, Left LED normally
RED, Right LED GREEN on
read on read
4-bit
607xAKN 00 1 1 0 0
02FM-0228
CSN Only
32 bit MSB
Beep ON, Left LED normally
RED, Right LED GREEN on
read on read
8-bit
607xAKN 00 1 1 0 9
02FM-0285
CSN Only
40 bit LSB
Beep OFF, Left LED normally
OFF, Right LED GREEN on
read on read
4-bit
607xAKN 03 1 4 0 0
02FM-0286
CSN Only
40 bit LSB
Beep OFF, Left LED normally
OFF, Right LED GREEN on
read on read
8-bit
607xAKN 03 1 4 0 9
02FM-0249
CSN Only
40 bit LSB
Beep OFF, Left LED normally
RED, Right LED GREEN on
read on read
4-bit
607xAKN 01 1 4 0 0
02FM-0250
CSN Only
40 bit LSB
Beep OFF, Left LED normally
RED, Right LED GREEN on
read on read
8-bit
607xAKN 01 1 4 0 9
02FM-0267
CSN Only
40 bit LSB
Beep ON, Left LED normally
OFF, Right LED GREEN on
read on read
4-bit
607xAKN 02 1 4 0 0
02FM-0268
CSN Only
40 bit LSB
Beep ON, Left LED normally
OFF, Right LED GREEN on
read on read
8-bit
607xAKN 02 1 4 0 9
02FM-0231
CSN Only
40 bit LSB
Beep ON, Left LED normally
RED, Right LED GREEN on
read on read
4-bit
607xAKN 00 1 4 0 0
02FM-0232
CSN Only
40 bit LSB
Beep ON, Left LED normally
RED, Right LED GREEN on
read on read
8-bit
607xAKN 00 1 4 0 9
