August 28, 2009 Page 2 of 9
© 2009 HID Global Corporation. All rights reserved.
SmartID Generic Configuration Guide, D00844, A.4
Format Configurations
SmartID HID MIFARE Application
Applicable Part Numbers (Reader / Application):
 8030DSHC SmartID S10 Read Only Reader, HID MIFARE
 8031DSHC SmartID SK10 Read Only Keypad Reader, HID MIFARE
Format
Number Card Read
Mode
CSN
Wiegand
Output Mode
Beeper/LED Configuration
Keypad Output
(if applicable) Equivalent FlexSmart
Part Suffix
02FM-0277
HID Data
Only
N/A
Beep OFF, Left LED normally
OFF, Right LED GREEN on
read on read
4-bit 607xAKN 03 0 0 0 0
02FM-0278
HID Data
Only
N/A
Beep OFF, Left LED normally
OFF, Right LED GREEN on
read on read
8-bit 607xAKN 03 0 0 0 9
02FM-0239
HID Data
Only
N/A
Beep OFF, Left LED normally
RED, Right LED GREEN on
read on read
4-bit 607xAKN 01 0 0 0 0
02FM-0242
HID Data
Only
N/A
Beep OFF, Left LED normally
RED, Right LED GREEN on
read on read
8-bit 607xAKN 01 0 0 0 9
02FM-0259
HID Data
Only
N/A
Beep ON, Left LED normally
OFF, Right LED GREEN on
read on read
4-bit 607xAKN 02 0 0 0 0
02FM-0260
HID Data
Only
N/A
Beep ON, Left LED normally
OFF, Right LED GREEN on
read on read
8-bit 607xAKN 02 0 0 0 9
02FM-0223
HID Data
Only
N/A
Beep ON, Left LED normally
RED, Right LED GREEN on
read on read
4-bit 607xAKN 00 0 0 0 0
02FM-0224
HID Data
Only
N/A
Beep ON, Left LED normally
RED, Right LED GREEN on
read on read
8-bit 607xAKN 00 0 0 0 9
02FM-0291
HID Data or
CSN
26 bit LSB
Beep OFF, Left LED normally
OFF, Right LED GREEN on
read on read
4-bit 607xAKN 03 2 2 0 0
02FM-0292
HID Data or
CSN
26 bit LSB
Beep OFF, Left LED normally
OFF, Right LED GREEN on
read on read
8-bit 607xAKN 03 2 2 0 9
02FM-0255
HID Data or
CSN
26 bit LSB
Beep OFF, Left LED normally
RED, Right LED GREEN on
read on read
4-bit 607xAKN 01 2 2 0 0
02FM-0256
HID Data or
CSN
26 bit LSB
Beep OFF, Left LED normally
RED, Right LED GREEN on
read on read
8-bit 607xAKN 01 2 2 0 9
02FM-0273
HID Data or
CSN
26 bit LSB
Beep ON, Left LED normally
OFF, Right LED GREEN on
read on read
4-bit 607xAKN 02 2 2 0 0
