HID SmartID Configuration Guide - Manual (Page 4)

August 28, 2009 Page 4 of 9
© 2009 HID Global Corporation. All rights reserved.
SmartID Generic Configuration Guide, D00844, A.4
Format
Number Card Read
Mode
CSN
Wiegand
Output Mode
Beeper/LED Configuration
Keypad Output
(if applicable) Equivalent FlexSmart
Part Suffix
02FM-0272
HID Data or
CSN
32 bit MSB
Beep ON, Left LED normally
OFF, Right LED GREEN on
read on read
8-bit 607xAKN 02 2 1 0 9
02FM-0235
HID Data or
CSN
32 bit MSB
Beep ON, Left LED normally
RED, Right LED GREEN on
read on read
4-bit 607xAKN 00 2 1 0
02FM-0236
HID Data or
CSN
32 bit MSB
Beep ON, Left LED normally
RED, Right LED GREEN on
read on read
8-bit 607xAKN 00 2 1 0
02FM-0293
HID Data or
CSN
40 bit LSB
Beep OFF, Left LED normally
OFF, Right LED GREEN on
read on read
4-bit 607xAKN 03 2 4 0 0
02FM-0294
HID Data or
CSN
40 bit LSB
Beep OFF, Left LED normally
OFF, Right LED GREEN on
read on read
8-bit 607xAKN 03 2 4 0 9
02FM-0257
HID Data or
CSN
40 bit LSB
Beep OFF, Left LED normally
RED, Right LED GREEN on
read on read
4-bit 607xAKN 01 2 4 0 0
02FM-0258
HID Data or
CSN
40 bit LSB
Beep OFF, Left LED normally
RED, Right LED GREEN on
read on read
8-bit 607xAKN 01 2 4 0 9
02FM-0275
HID Data or
CSN
40 bit LSB
Beep ON, Left LED normally
OFF, Right LED GREEN on
read on read
4-bit 607xAKN 02 2 4 0 0
02FM-0276
HID Data or
CSN
40 bit LSB
Beep ON, Left LED normally
OFF, Right LED GREEN on
read on read
8-bit 607xAKN 02 2 4 0 9
02FM-0237
HID Data or
CSN
40 bit LSB
Beep ON, Left LED normally
RED, Right LED GREEN on
read on read
4-bit 607xAKN 00 2 4 0 0
02FM-0238
HID Data or
CSN
40 bit LSB
Beep ON, Left LED normally
RED, Right LED GREEN on
read on read
8-bit 607xAKN 00 2 4 0 9
