EDGE EVO Hi-O Networked Controller
EH400
Direct Connect
If connecting EDGE EVO to a network using static IP addressing or if the Discovery GUI is not installed on the PC, use this
method.
Note: The computer must be running Windows 2000 or XP and be configured for DHCP.
1. Disconnect the computer from the network and directly connect EDGE EVO to the computer with an Ethernet cable.
2. Click
Start > Run. Enter ipconfig /renew ↵
3. Access a web browser and enter 169.254.242.121 into the Address field ↵
Discovery GUI (for DHCP networks)
With a DHCP network, use the HID Discovery GUI on the PC to locate and connect the Controller.
Note: The Controller must be connected to the network before power is applied for DHCP to function.
1. With the PC connected to the same network as the Controller, double-click hid-discovery.exe.
2. Select the device from the list.
3. Click
Browser.
If the Discovery GUI is not on the PC, download the application from www.hidglobal.com/downloads/DiscoveryClient.zip .
Note: Java is required for the Discovery GUI.
The web browser will prompt for login information. From the Login screen enter admin, leaving the Password field empty.
Follow the instructions on the web browser screen to configure EDGE EVO.
For EDGE EVO Solo, reference the EDGE EVO Solo User Guide, 83000-902, rev B.x.
Contact
5
Configure
6
