NOTICE: Refer to your helicopter, gyro and governor manuals
for programming recommendations.
CAUTION: Always do a Control Test of your model with the transmitter
after programming changes to make sure your model responds as desired.
Swash Type
The Swash Type menu option assigns
the swash type for your particular
helicopter model.
Select the Swash Type before
completing any programming in the
Function List. The Swash Type will affect
menu options in the Function List.
Collective Type
The collective type is used to turn
on “Pull” collective for reversed
collective. Available settings are Normal
and Reverse. Press NEXT from the
Swashplate Type screen to access the
Collective Type screen. The Collective
Type allows the throttle/pitch stick to operate in reverse and ensures trims, curves
and all other functions that are to work in reverse function properly.
Image Selection
Press the NEXT screen from the
Collective Type screen to access the
Helicopter Image screen and to select
an optional helicopter image to use for
the model selected.
Pitch Curve
This function supports adjustment of
collective pitch in 5 fl ight modes.
To adjust the Pitch Curve:
1. Select the Pitch Curve you wish to
edit (N, 1 or 2).
2. Scroll right to select the points on
the curve and edit the respective values.
3. Press the BACK button to save the Pitch Curves and return
to the Function List.
HELI (Helicopter)
