18 SPEKTRUM DX18QQ EN
X-Plus Channels and Failsafe
Failsafe is not supported for servos connected to the X-Plus Module. We recom-
mend that no failsafe should be expected or attempted for a servo connected
through the X-Plus Module. However, servos connected to the X-Plus Module will
hold last command in the event of a failsafe condition.
To Activate X-Plus
1. Open the Frame Rate Menu in
System Setup.
2. Scrolll to X-Plus and press the
scroll wheel to activate. The X-Plus
Inputs screen is now active in the
Channel Assign menu.
AUX6 and AUX7 channels are available on 12-channel receivers when X-Plus is
active. AUX6 and AUX7 are 2048 resolution and 22ms frame rate (12-channel
receivers only).
Channels X+1 and X+2 are duplicate
channels of channels 11 and 12 on a
12-channel receiver with X-Plus active.
If channels 11 and 12 require any
adjustment for travel adjust, servo
reversing, sub trim or any other function,
adjust channels X+1 and X+2.
Note that channels 11 and 12 will
also show on the X-Plus monitor as
channels X+1 and X+2.
If you select 11ms frame rate before you activate X-Plus, the transmitter reverts
to 22ms frame rate when X-Plus is active.
CAUTION: Do NOT connect throttle or any primary control surface to the
X-Plus Module. The X-Plus channels are intended to be used for auxiliary
functions only. X-Plus channels have a resolution of 512 and variable latency from
22ms to about 88ms. When X-Plus is active, the fi rst 10 channels default to 22ms.
Refer to community.spektrumrc.com for more information about X-Plus options.
from Channel Assign menu
