36 SPEKTRUM DX18QQ EN
Function List
Servo Setup
The Servo Setup menu contains the following functions:
• Travel Adjust
• Sub-Trim
• Reverse
• Speed
• Abs. (Absolute) Travel
• Balance
Travel Adjust
Travel Adjust sets the overall travel or
endpoints of the servo arm movement.
To adjust travel values:
1. Scroll to the channel you wish to
adjust and press the scroll wheel.
When adjusting travel values as-
signed to a control stick:
a. Center the control stick to adjust
both directions at the same time.
b. To adjust travel in one direction only, move the control stick in the direc-
tion you wish to adjust. Continue holding the control stick in the desired
direction while you are adjusting the travel value.
2. Scroll left or right to adjust the travel value. Press the scroll wheel to save the
selection.
Sub-Trim
Sub-Trim adjusts the servo travel center
point. If X-Plus is active, sub-trim for
X-Plus channels appears on the second
screen.
CAUTION Use only small sub-
trim values or you may cause
damage to the servo.
Reverse
Use the Reverse menu to reverse the
channel direction. For example, if the
elevator servo moves up and it should
move down.
To reverse a channel direction:
1. Scroll to Travel and press the scroll
wheel. Scroll left until Reverse
appears and press the scroll wheel again to save the selection.
2. Scroll to the channel you wish to reverse and press the scroll wheel.
CAUTION: If you reverse the Throttle channel, a confi rmation screen
appears. Select YES to reverse the channel. A second screen appears, re-
minding you to bind your transmitter and receiver. Failure to re-bind the transmit-
ter and receiver will result in the throttle moving to full throttle if failsafe activates.
CAUTION: Always perform a control test after making adjustments to
confi rm the model responds properly. After adjusting servos, always rebind
the transmitter and receiver to set the failsafe position.
Select this when X-Plus
channels are active
