9. The next step is to start connecting the cooling components with each other, following the recommendations described in the
schematics below. It is important to avoid sharp bends. Excessive bending will result in collapsing the tube, causing severe
restriction to the coolant flow rate. Highest possible flow rate is essential to proper cooling.
P u m p
o u t l e t
P u m p
i n l e t
Always connect individual
components from bottom to
top, so that the liquid naturally
pushes the air up and out,
during the fill and bleed process
If radiator is installed sideways
connect the lowest tube to be
the inlet
If radiator is installed
straight up, you can use
either one of the tubes for
inlet and outlet
From water-block
To fill and bleed
From pump
To radiator
To fill and bleed
Feed
bottle
Fill & bleed kit
Pump
Open
Open
MCR80
Closed
MCW5000
From
pump
To radiator
TUBE ROUTING AND
FILL & BLEED OPERATIONS
WITHOUT VGA COOLING
