10 OM-SBF
Maintenance
The connectionless steamers are designed for minimum maintenance, and no user
adjustments should be necessary. Certain parts may need replacement after pro-
longed use. If there is a need for service, only authorized representatives should
perform the work.
If steam or condensate is seen leaking from around the door, take the following steps:
1. Check the door gasket. Replace it if it is cracked or split.
2. Inspect the cooking chamber exhaust to be sure it is not blocked.
3. Adjust the door latch pin to allow for changes that might occur as the gasket
ages.
a. Loosen the lock nut at the base of the latch pin, then turn the latch pin
1/4 turn clockwise, and tighten the lock nut.
b. After adjustment, run the unit to test for further steam leakage.
c. If there is still leakage, repeat the adjustment.
d. Continue adjusting the pin clockwise until the door fits tightly enough to
prevent leakage.
