5
Installation
Oven Assembly
PACKAGING
Before assembly and installation of the oven, check that
all components have been received. In addition to the
oven, legs, decks and/or other accessories may be re-
quired.
Single Sections
• 4” (10 cm) legs are shipped inside the oven, packed
in a separate carton.
• The decks are individually packaged and secured to
the oven back.
Double Sections
• 4” (10 cm) legs are packed in lower sections.
• Spacer is shipped attached to the upper section.
• Securing plate to attach units together is located in
the upper section.
• The decks are packaged with each section.
LEG ATTACHMENT
1. Tip bottom oven section backward.
2. Attach each of the four legs into the nuts secured in
the oven bottom.
3. Tighten each leg and adjust the leg feet to approxi-
mately the same height.
NOTE: Final leg fet adjustment will be required dur-
ing the leveling operation.
Figure 2
