AT-8316F and AT-8324 Installation Guide
87
Table B-3 shows the pin assignments for the R.P.S. Input port on the
back of the switch. (Pin numbers 1 through 8 are the bottom row of
pins on the connector, with pin 1 in the bottom right corner. Pin
numbers 9 through 16 are the top row, with pin 9 in the top right
position on the connector.)
Table B-3 R.P.S. Input Port Pin Assignments
Pin Number Function
1 +12V dc
2
Remote Sense (RS) +5V dc
3 RS Ground
4 RS +3.3V dc
5 Redundant Power Supply (RPS) Present
6 Ground (+3.3V dc Return)
7 Ground (+5V dc Return)
8 +5V dc
9
Ground (+12V dc Return)
10 +3.3V dc
11 Ground (+3.3 dc Return)
12 +3.3V dc
13 Ground (+3.3V dc Return)
14
+3.3V dc
15 +5V dc
16 Ground (+5V dc Return)
