Allied Telesis AT-8324 User Manual
Page 86
Technical Specifications
86
Table B-2 shows the pin assignments for the switch’s RJ-45 connectors.
Table B-2 RJ-45 Port Pin Assignments
Pin Number
Function
1
RD+
2
RD-
3
TD+
4
Unused
5
Unused
6
TD-
7
Unused
8
Unused
