Hardware Description
20
Stacking Module Expansion Slot
The stacking module expansion slot on the back panel of the switch
is for the optional AT-Stack8 Stacking Matrix Module. This module
allows you build a logical switch of up to eight switches.
Stack ID Switch
Next to the stacking ports on the back panel of the switch is the Stack
ID switch (shown in Figure 1-8). You use this switch when you build a
stack to assign each switch a unique identification number.
Figure 1-8 Stack ID Switch
Note
While the Stack ID switch has the range of settings of 0 to 9, only
settings 1 through 8 are valid settings. Settings of 0 and 9 are
invalid and should not be used. For information on setting this
switch, refer to Chapter 3, Installing the Switch.
IS-A IS-B STACK ID
0
STACK ID
1
