Technical Specifications
B-2
Media Dependent Adapter Cabling Distances
Table B-3 lists the maximum cable distances for the AT-3714F,
AT-3726 Switch Media Dependent Adapter (MDA).
Table B-2 RJ45 Pin Assignments for AT-3714F (Mirror port) and AT-3726
Pin Number Function
1 RD+
2 RD-
3 TD+
4 Unused
5 Unused
6 TD-
7 Unused
8 Unused
Table B-3 MDA Maximum Cable Distances
MDA Ethernet Type Maximum Distance
AT-3701F/SC SC (100Base) 1.25 miles (2 km for full duplex,
412 M for half duplex) 50/125
and 62.5/125 micron multimode
fiber cable
AT-3701 RJ45 (10/100Base) 330 ft. (100m), twisted pair
Category 5 UTP
