AT-S79 Management Software User’s Guide
Section I: Using the Menus Interface 99
Mapping CoS Priorities to Egress Queues
This procedure explains how to change the default mappings of CoS
priorities to egress priority queues, shown in Table 2 on page 97. This is
set at the switch level and applies to all ports. This procedure also enables
and disables QoS.
To change the mappings, perform the following procedure:
1. From the Main Menu, type A to select Advanced Switch
Configuration.
The Advanced Switch Configuration Menu is shown in Figure 14 on
page 59.
2. From the Advanced Switch Configuration Menu, type S to select
Quality of Service Configuration.
The Quality of Service Configuration Menu is shown in Figure 23.
Figure 23. Quality of Service Configuration Menu
3. From the Quality of Service Configuration Menu, type T to select
Traffic Class Configuration.
AT-GS950/16 Local Management System
Advanced Switch Configuration -> Quality of Service Configuration Menu
[T]raffic Class Configuration
[P]ort Priority Configuration
[Q]uit to previous menu
Command>
