Chapter 4: Port Configuration
50 Section I: Using the Menus Interface
Displaying the Port Parameters
To display the parameter settings for the ports on the switch, perform the
following procedure:
1. From the Main Menu, type B to select Basic Switch Configuration.
The Basic Switch Configuration Menu is shown in Figure 4 on page 30.
2. From the Basic Switch Configuration Menu, type P to select Port
Configuration.
The Port Configuration Menu is shown in Figure 13.
Figure 13. Port Configuration Menu
AT-GS950/16 Local Management System
Basic Switch Configuration -> Port Configuration Menu
Port Trunk Type Link Status Mode Flow Ctrl
---- ----- ------ ---- ------ ---------------------
1 --- 1000tx Up Enabled Auto (100F) Enabled
2 --- 1000tx Up Enabled Auto (100F) Enabled
3 --- 1000tx Up Enabled 100-FDx Enabled
4 --- 1000tx Up Enabled Auto (1000F) Enabled
5 --- 1000tx Up Enabled Auto (100F) Enabled
6 --- 1000tx Down Enabled Auto Enabled
7 --- 1000tx Up Enabled Auto (1000F) Enabled
8 --- 1000tx Down Enabled Auto Enabled
9 --- 1000tx Up Enabled Auto (1000F) Enabled
10 --- 1000tx Up Enabled 100-FDx Enabled
11 --- 1000tx Up Enabled 10-FDx Enabled
12 --- 1000tx Up Enabled Auto (100F) Enabled
----------------------- ------------------------------------
[N]ext Page
Set [S]tatus Set [F]low Control
[P]revious Page Set [M]ode [Q]uit to previous menu
Command>
