Allied Telesis AT-S79 - Manual (Page 158)

Chapter 15: Port Configuration
158 Section II: Using the Web Browser Interface
Viewing and Configuring Ports Using the Port Configuration Page
This procedure explains how to configure the ports on the switch using the
Port Configuration page. This page allows you to view and configure the
parameter settings of all the switch ports at one time.
To configure the ports, perform the following procedure:
1. From the Basic Config menu, select Port Config.
The Port Configuration page is shown in Figure 43. The page lists all
the ports on the switch and their current settings.
Figure 43. Port Configuration Page
2. Adjust the port settings as needed. Not all parameters are adjustable.
The parameters are defined here:
Port Index
The port number. You cannot change this parameter.
Trunk
The trunk group number. A number in this column indicates that the
port has been added to a trunk. For information about configuring a
trunk, refer to Chapter 16, “Port Trunking” on page 167.
