Chapter 7: Virtual LANs
84 Section I: Using the Menus Interface
Creating a VLAN
This section contains the procedure for creating a new port-based or
tagged VLAN. This procedure assigns the VLAN a name, a VID number,
and the untagged and tagged member ports.
After you have performed this procedure, you must configure the
untagged ports of the VLAN by adjusting their PVID values to match the
virtual LAN’s VID number. The PVID value of a port must match its virtual
LAN’s VID in order for a port to be considered an untagged member of the
VLAN. This procedure is found in “Configuring the PVID of Untagged
Ports” on page 87.
To create a VLAN, perform the following procedure:
1. From the Main Menu, type A to select Advanced Switch
Configuration.
The Advanced Switch Configuration Menu is shown in Figure 14 on
page 59.
2. From the Advanced Switch Configuration Menu, type V to select
VLAN Management.
The VLAN Management Menu is shown in Figure 20.
Figure 20. VLAN Management Menu
AT-GS950/16 Local Management System
Advanced Switch Configuration -> VLAN Management Menu
VLAN ID VLAN Name VLAN Type
------- --------------------- ----------
1 Default VLAN Permanent
3 Marketing Static
----------------------- ------------------------------------
[N]ext Page
[C]reate VLAN C[o]nfig VLAN Member
[P]revious Page [D]elete VLAN [S]et Port Config
[R]eset VLAN to Default [Q]uit to Previous Menu
Command>
