Appendix A: Technical Specifications
38
Serial Port Wiring
The CONSOLE port is an RJ45 connection (not a DB9 connection used with
other Allied Telesis products). Pinout is as follows.
Note
When looking at the RJ-45 port, pin 1 is on the right.
• Pin 3 -TXD
• Pin 6 - RXD
• Pin 4 (or 5) - GND
T1/E1 Cable Wiring
• Pin 1 - Rx, Ring
• Pin 2 - RX, Tip
• Pin 4 - TX, Ring
• Pin 5 - TX, Tip
• Pins 3, 6 - No Conection
• Pins 7,8 - Ground
