AT-iMG646MOD Installation Guide
20 Chapter 4: Installing the Gateway Indoors
Preparing for the Installation
To prepare for the installation, perform the following procedure:
1. Remove all components from the shipping package.
Note
Store the packaging material in a safe location. You must use the original shipping material if you need
to return the unit to Allied Telesis.
2. Ensure that the following components are included in the gateway package. If any item is missing or
damaged, contact your Allied Telesis sales representative for assistance.
ˆ AT-iMG646MOD chassis (LAN and WAN cards are already installed)
ˆ This Installation Guide
ˆ Accessory Kit that includes:
– 6-pin DC terminal block
– 2 #8-32 SEMS pan head Phillips screws (used for mounting the grounding
stud and attaching the electronics unit to the wall mount bracket)
Note
The wall mount bracket (needed for indoor installation as performed here) can be provided by the
customer or can be ordered.
